Similarly, the contact between the involute curves that form the meshing teeth of two gears are cam joints, as is a wheel rolling on a surface. For example, the contact between a cam and its follower is a higher pair called a cam joint. Generally, a higher pair is a constraint that requires a curve or surface in the moving body to maintain contact with a curve or surface in the fixed body.
This joint has three degrees of freedom, corresponding to rotations around orthogonal axes. A spherical S joint or ball and socket joint requires that a point in the moving body remain stationary in the fixed body.A universal U joint consists of two intersecting, mutually orthogonal revolute joints connecting rigid links whose axes are inclined to each other.It is a combination of a revolute joint and a sliding joint. A cylindrical C joint requires that a line in the moving body remain co-linear with a line in the fixed body.A screw joint or helical H joint requires cut threads in two links, so that there is a turning as well as sliding motion between them.This imposes five constraints on the relative movement of the links, which therefore has one degree of freedom. A prismatic P joint, or slider, requires that a line in the moving body remain co-linear with a line in the fixed body, and a plane parallel to this line in the moving body maintain contact with a similar parallel plane in the fixed body.A revolute R joint, or hinged joint, requires a line in the moving body to remain co-linear with a line in the fixed body, and a plane perpendicular to this line in the moving body maintain contact with a similar perpendicular plane in the fixed body.nut and screw, universal joint used to connect two propeller shafts.
A lower pair is one in which there occurs a surface or area contact between two members, e.g. In studies of mechanisms, manipulators or robots, the two objects are typically called ‘links’.Ī lower pair is an ideal joint that constrains contact between a surface in the moving body to a corresponding in the fixed body. In kinematics, the two connected physical objects, forming a kinematic pair, are called `rigid bodies’. Lower pairs are those for which area contact may be visualized, as in pin connections, crossheads, ball-and socket joints and some others the relative motion of coincident points of the elements, and hence of their links, are similar, and an exchange of elements from one link to the other does not alter the relative motion of the parts as it would with higher pairs. With higher pairs, the two elements are in contact at a point or along a line, as in a ball bearing or disk cam and follower the relative motions of coincident points are dissimilar.
In the matter of connections between rigid bodies, Reuleaux recognized two kinds he called them higher and lower pairs (of elements). Hartenberg & Denavit presents the definition of a kinematic pair:
Kinematics as a field of study is often referred to as the "geometry of motion". Kinematics is the branch of classical mechanics which describes the motion of points, bodies (objects) and systems of bodies (groups of objects) without consideration of the causes of motion.
